Siemens SINUMERIK 840D Operator's Guide

5
03.04 "Parameters" Operating Area
5.3 Tool mana
g
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-195
WTy
Tool type
Only some of the tool offsets are enabled for input, depending on the
tool type.
All other tool types are preset to a value of 0.
Geo – Len 1
Radius ...
Tool offsets such as length, radius, wear, monitoring data, etc.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
