Page #197 background image
5
03.04 "Parameters" Operating Area
5.3 Tool mana
g
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-197
(Names assigned by
user)
Vertical softkeys (magazine list)
Selection of user-specific display windows (if configured), e.g.
Magazine
list 1
· General data
Magazine
list 2
· Geometry tool data
Magazine
list 3
· Wear data
Tool
data
You can display and edit the complete data of a tool.
Call up the start screen for updating the tool data. You can display
and normally also modify all the data of the tool, its cutting edges and
its working offsets in this screen and subsidiary screens. The vertical
softkey bar changes.
The exact procedure is described under "Displaying/modifying tool
data" (see "Displaying/modifying tool data" ff).
Activate
D check
Two functions are implemented with this softkey:
· Verify unique D number assignment
Duplication can occur when assigning D numbers to the cutting
edges of the individual tools. This function checks all numbers
within the current magazine or all allocated D numbers within a TO
unit (configured by parameter).
· Activating the tools
If unique D numbers were assigned, a wear group is activated. A
tool is subsequently activated from each replacement tool group in
the TOA of the current channel. Allowance is made for the active
wear group.
Only automatically accessible magazines are considered for
processing. Any previously active tools are disabled by the activation
of tools, especially if the wear group is changed.
