5
03.04 "Parameters" Operating Area
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-223
Additional functions
The "Delete" function is also available in the tool cabinet. It is not
possible to copy or create a new ideal tool here (only in the tool
catalog).
Delete
The currently selected tool is deleted from the tool cabinet after a
prompt.
All data of the tool with this Duplo number are lost. The master data in
the tool catalog are not affected (tool with Duplo number 0).
Other information
The "Tool offset data", "Cutting edge user data" and "Tool user data"
softkeys are always displayed when you edit the tool details. This
allows you to move between the individual tables as required.
A tool entered in the cabinet can be loaded to a magazine location via
softkey "Tool from cabinet".
