5
03.04 "Parameters" Operating Area
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-225
Functional
description
Operator interface:
The "Job processing for tools" function is selected via the horizontal
softkey "Filter lists" from the basic states of the magazine and tool
lists in the tool management.
The "Job processing for tools" recognizes three states, which are
represented by different screens:
1. Select a filter
2. Displays the hit list, tool selection and start of job processing in 2
screens: Load job list and standard job list.
3. Job execution
Each TOA (data area for tool offsets) has a separate state. You can
exit the "Filter lists" in these states and display different tool
management screens or switch to other operating areas.
The next time you press the horizontal "Filter lists" softkey, the screen
for the noted state is displayed.
The 2nd state "Hit list" stores the hit list and the tool selection as a
snapshot.
The 3rd state "Job execution" stores the data for the selected tools
and the job type. You can exit the "Filter lists" during job processing.
After returning to the "Filter lists", the new status of job processing is
displayed. The status of the job as a whole and the states of the
individual job elements are visible.
Paramtm.ini
You can set the user rights for the softkeys involved in the
paramtm.ini file (section [ACCESSLEVEL], entries "SKB...").
The filter lists are parameterized in the paramtm.ini file in the
[BatchTools] section.
Country-specific sections are parameterized in the
"language\patm_xx.ini" file in the [BatchTools] section; "xx"
stands for the 2 letters user for the country code.
