5
03.04 "Parameters" Operating Area
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-227
II.
Hit list in the
"Load point" and
"Standard list" screens
The "Hit list" screen has one of 2 configuration-dependent variants:
· Load point with the functions "Load" and "Reactivate"
· Standard list with the functions "Reactivate", "Unload", "Delete",
"In cabinet".
When filtering has started in screen 1 "Filter selection", the tools found
in screen 2 "Hit list" are displayed in a list with one line per tool.
The data displayed is a snapshot which was created at the time of
filtering; it is not subsequently updated when the data changes in
the NC.
Selection of tools
No tool is selected for job processing at the outset. By positioning the
cursor and pressing the Select key, you can toggle the tool selection
for job processing. To change the tool selection for job processing,
you can use the softkeys "Select all" and "Deselect".
Selected tools are represented in color and also indicated by a symbol
in the 2nd column of the hit list on the display screen.
In the default setting, a tool selected for batch processing is displayed
with a checked checkbox symbol (
and . The color for
"Cursor" and for "Selected for job processing" is identical and
corresponds to the general selection display.
When selection of the tools is completed, press the softkey to start the
batch function.
