6
03.04 "Program" Operating Area
6.10 Mana
e
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 6-341
Operating sequence
Workpieces
The current overview of all workpiece directories appears on the
screen.
New
Input window "New" is opened.
The cursor is located in the input field for the name of the new
workpiece directory.
Enter the name of the new directory on the alphanumeric keyboard.
Specify the created type in the data type field: WPF
If there are any templates for the specified data type in the Templates
directory they are offered for selection. Press OK to confirm your
selection.
A new directory is set up in the workpiece overview.
You are asked straight away for the name of the first part program
and the Editor is opened.
When creating a workpiece with New, all templates corresponding to
your selection are only copied from the Templates\Siemens ...
Manufacturer ... User directory to Startup\Settings\Templates if "No
template" is selected in the Templates selection field.
If a template is proposed for the workpiece, then all elements
assigned to it such as job list, part program, subroutines are
transferred to the new workpiece in compliance with the template and
its language-specific elements.
For more information, see Subsection 6.1.5 Templates
