9
"Startup" Operating Area 03.04
9.2 User views
9
Ó Siemens AG, 2004. All rights reserved
9-446 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Only axis-specific machine data:
In the "Axis" field it is possible to enter the axis number or select the
appropriate axis from a list. Axis numbers and axis names are marked
with a "*" in the user view until their assignment changes.
Manage
views
Assign
softkey ...
Delete
Save
Load
The vertical softkey bar changes. In the "Manage views" menu, you
can now work with your own user view. It is possible to assign your
user views to six horizontal softkeys and call them at anytime. The
currently active user view is always assigned.
Note
When you switch to "User views", the user view of the first assigned
softkey is automatically displayed (usually softkey 1). If you do not
enter a name in the "File" field in the "Assign softkey" menu, the
currently active user view will also be deleted.
The view can only be assigned to the softkey if a name is entered.
The currently active user view is deleted.
You can save the currently active user view.
A specific user view can be loaded by entering the file name.
