A Appendix
590
7UT613/63x Manual
C53000-G1176-C160-2
192.2413 Dynamic settings O/C 3I0 are
ACTIVE (3I0 Dyn.set.ACT)
ColdLoadPickup OUT ON
OFF
ON
OFF
* LED BO 60 249 1 Yes
193 Alarm: Analog input adjustment
invalid (Alarm adjustm.)
Supervision OUT ON
OFF
* * LED BO 135 181 1 Yes
196 Fuse Fail Monitor is switched
OFF (Fuse Fail M.OFF)
Supervision OUT ON
OFF
**LEDBO
198 Error: Communication Module B
(Err. Module B)
Supervision OUT ON
OFF
* * LED BO 135 198 1 Yes
199 Error: Communication Module C
(Err. Module C)
Supervision OUT ON
OFF
* * LED BO 135 199 1 Yes
199.2404 >BLOCK restricted earth fault
prot. (>BLOCK REF)
REF SP * * * LED BI BO
199.2411 Restricted earth fault is switched
OFF (REF OFF)
REF OUT ON
OFF
**LEDBO76111Yes
199.2412 Restricted earth fault is
BLOCKED (REF BLOCKED)
REF OUT ON
OFF
ON
OFF
* LED BO 76 12 1 Yes
199.2413 Restricted earth fault is ACTIVE
(REF ACTIVE)
REF OUT ON
OFF
**LEDBO76131Yes
199.2421 Restr. earth flt.: picked up (REF
picked up)
REF OUT * ON
OFF
m LED BO 76 17 2 Yes
199.2451 Restr. earth flt.: TRIP (REF TRIP) REF OUT * ON m LED BO 176 89 2 No
199.2491 REF err.: Not available for this
object (REF Not avail.)
REF OUT ON * * LED BO
199.2492 REF err.: No starpoint CT (REF
Err CTstar)
REF OUT ON * * LED BO
199.2494 REF err.: adverse Adaption factor
CT (REF Adap.fact.)
REF OUT ON * * LED BO
199.2631 Restr. earth flt.: Time delay
started (REF T start)
REF OUT * ON
OFF
* LED BO 76 16 2 Yes
199.2632 REF: Value D at trip (without
Tdelay) (REF D:)
REF VI * ON
OFF
76 26 4 No
199.2633 REF: Value S at trip (without
Tdelay) (REF S:)
REF VI * ON
OFF
76 27 4 No
199.2634 REF: Adaption factor CT M1
(REF CT-M1:)
REF VI ON
OFF
199.2635 REF: Adaption factor CT M2
(REF CT-M2:)
REF VI ON
OFF
199.2636 REF: Adaption factor CT M3
(REF CT-M3:)
REF VI ON
OFF
199.2637 REF: Adaption factor CT M4
(REF CT-M4:)
REF VI ON
OFF
199.2638 REF: Adaption factor CT M5
(REF CT-M5:)
REF VI ON
OFF
199.2639 REF: Adaption factor CT starpnt.
wind. (REF CTstar:)
REF VI ON
OFF
200 Error: Communication Module D
(Err. Module D)
Supervision OUT ON
OFF
* * LED BO 135 200 1 Yes
200.2404 >BLOCK Time Overcurrent
1Phase (>BLK 1Ph. O/C)
1Phase O/C SP * * * LED BI BO
200.2411 Time Overcurrent 1Phase is OFF
(O/C 1Ph. OFF)
1Phase O/C OUT ON
OFF
* * LED BO 76 161 1 Yes
200.2412 Time Overcurrent 1Phase is
BLOCKED (O/C 1Ph. BLK)
1Phase O/C OUT ON
OFF
ON
OFF
* LED BO 76 162 1 Yes
200.2413 Time Overcurrent 1Phase is
ACTIVE (O/C 1Ph. ACT)
1Phase O/C OUT ON
OFF
* * LED BO 76 163 1 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
