A Appendix
592
7UT613/63x Manual
C53000-G1176-C160-2
205.2404 >BLOCK restricted earth fault
prot. 2 (>BLOCK REF2)
REF 2 SP * * * LED BI BO
205.2411 Restricted earth fault 2 is
switched OFF (REF2 OFF)
REF 2 OUT ON
OFF
**LEDBO
205.2412 Restricted earth fault 2 is
BLOCKED (REF2 BLOCKED)
REF 2 OUT ON
OFF
ON
OFF
* LED BO
205.2413 Restricted earth fault 2 is ACTIVE
(REF2 ACTIVE)
REF 2 OUT ON
OFF
**LEDBO
205.2421 Restr. earth flt. 2: Time delay
started (REF2 T start)
REF 2 OUT * ON
OFF
m LED BO
205.2451 Restr. earth flt. 2: TRIP (REF2
TRIP)
REF 2 OUT * ON m LED BO
205.2491 REF2 err.: Not available for this
object (REF2 Not avail.)
REF 2 OUT ON * * LED BO
205.2492 REF2 err.: No starpoint CT (REF2
Err CTstar)
REF 2 OUT ON * * LED BO
205.2494 REF2 err.: adverse Adaption
factor CT (REF2 Adap.fact.)
REF 2 OUT ON * * LED BO
205.2631 Restr. earth flt. 2: picked up
(REF2 picked up)
REF 2 OUT * ON
OFF
* LED BO
205.2632 REF2: Value D at trip (without
Tdelay) (REF2 D:)
REF 2 VI * ON
OFF
205.2633 REF2: Value S at trip (without
Tdelay) (REF2 S:)
REF 2 VI * ON
OFF
205.2634 REF2: Adaption factor CT M1
(REF2 CT-M1:)
REF 2 VI ON
OFF
205.2635 REF2: Adaption factor CT M2
(REF2 CT-M2:)
REF 2 VI ON
OFF
205.2636 REF2: Adaption factor CT M3
(REF2 CT-M3:)
REF 2 VI ON
OFF
205.2637 REF2: Adaption factor CT M4
(REF2 CT-M4:)
REF 2 VI ON
OFF
205.2638 REF2: Adaption factor CT M5
(REF2 CT-M5:)
REF 2 VI ON
OFF
205.2639 REF2: Adaption factor CT starp-
nt. wind. (REF2 CTstar:)
REF 2 VI ON
OFF
206.2404 >BLOCK Breaker failure 2
(>BLOCK BkrFail2)
Breaker Fail. 2 SP * * * LED BI BO
206.2411 Breaker failure 2 is switched OFF
(BkrFail2 OFF)
Breaker Fail. 2 OUT ON
OFF
**LEDBO
206.2412 Breaker failure 2 is BLOCKED
(BkrFail2 BLOCK)
Breaker Fail. 2 OUT ON
OFF
ON
OFF
* LED BO
206.2413 Breaker failure 2 is ACTIVE
(BkrFail2 ACTIVE)
Breaker Fail. 2 OUT ON
OFF
**LEDBO
206.2491 Breaker failure 2 Not avail.for this
obj (BkrFail2 Not av)
Breaker Fail. 2 OUT ON * * LED BO
206.2651 >Breaker failure 2 initiated exter-
nally (>BrkFail2extSRC)
Breaker Fail. 2 SP ON
OFF
**LEDBIBO
206.2652 Breaker failure 2 (internal)
PICKUP (BkrFail2 int PU)
Breaker Fail. 2 OUT * ON
OFF
* LED BO
206.2653 Breaker failure 2 (external)
PICKUP (BkrFail2 ext PU)
Breaker Fail. 2 OUT * ON
OFF
* LED BO
206.2654 BF 2 TRIP T1 (local trip) (BF2
T1TRIP(loc))
Breaker Fail. 2 OUT * ON m LED BO
206.2655 BF 2 TRIP T2 (busbar trip) (BF2
T2TRIP(bus))
Breaker Fail. 2 OUT * ON m LED BO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
