Mounting
5.15 Mounting the sealable cover
SIRIUS 3RM1 motor starter
Manual, 06/2016, A5E0345285095020A/RS-AE/005
109
Mounting the sealable cover
The sealable cover is used to protect the set rated operational current of the load
(current setting I
e
) against unauthorized or unintentional manipulation.
1 Attach the two bottom hooks on the cover to the
openings on the device and fold the cover up
2 Seal the cover to secure it against unauthorized
removal.
