Mounting
5.14 Disassembling the devices with device connectors from a wall
SIRIUS 3RM1 motor starter
Manual, 06/2016, A5E0345285095020A/RS-AE/005
107
Disassembling the devices with device connectors from a wall
Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power supplying this device before working on this device.
● The terminals have been removed or disconnected.
1 Unlock the device on the underside using a
screwdriver.
2 Pull the lower half of the device away from the
3 Unlock the device on the top using a screwdriver.
