Mounting
5.3
Disas
sembling t
he devi
ces from a lev
el surfac
e
SIRIU
S 3RM1
moto
r star
ter
Manual
,
06/2016
,
A5E0345285095020A/
RS
-
AE/005
89
5.3
Disassembling the devi
ces from a level surface
DANG
ER
Hazar
dous volt
age.
Will caus
e death or serious
injury.
Turn off
and lock out
all power
supplying th
is device
before wor
king on this
device.
Requirements
●
The term
inals have b
een re
moved or disc
on
nected.
Procedure
Step
Operating instr
uction
Figure
1
Hold the de
vice firm
ly.
2
Unscrew the cap screws.
3
Lift the device from
the level surface.
4
Rem
ove the secur
ing bracket
s from the d
evice.
88
90
