SIRIU
S 3RM1
moto
r star
ter
118
Manual
,
06/2016
,
A5E0345285095020A/
RS
-
AE/005
6.5
Attaching the terminals
DANG
ER
Hazar
dous volt
age.
Will caus
e death or serious
injury.
Turn off
and lock out
all power
supplying th
is device
before w
orking on t
his devic
e.
Requirements
●
You must
have remov
ed the term
inals, for t
he purpose
of replaci
ng a device, f
or ex
ample.
Procedure
Step
Operating instr
uction
Figure
1
Insert the
terminal in
to the gui
de rail of the
device.
2
Slide the terminal
back until it audibly enga
g
es.
117
119
