Description
3.6 Accessories and article number scheme
SIRIUS 3RM1 motor starter
Manual, 06/2016, A5E0345285095020A/RS-AE/005
51
3.6.2.3
Sealable cover
The sealable cover prevents unauthorized access to the rotary coding switch.
Table 3- 8 Article number of the sealable cover
Description
Article number
SIRIUS sealable cover 22.5 mm, cutout for pushbuttons at bottom 3ZY1321-2AA00
3.6.2.4
Wall mounting
The push-in lugs for wall mounting of the 3RM1 motor starter are inserted at the top and
bottom of the motor starter enclosure. This method is used to screw the motor starter onto
level mounting surfaces.
The wall fixture is inserted into the enclosure at the top and bottom for screw-mounting the
3RM1 motor starter to level mounting surfaces.
Table 3- 9 Article numbers of the push-in lugs for wall mounting
Description
Article number
SIRIUS push-in lugs for wall mounting
3ZY1311-0AA00
