Connection
6.4 Disconnecting the push-in terminals
SIRIUS 3RM1 motor starter
Manual, 06/2016, A5E0345285095020A/RS-AE/005
117
6.4
Disconnecting the push-in terminals
DANGER
Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power supplying this device before working on this device.
Requirements
● Screwdriver DIN 5264 of the size 0.5 x 3 mm
Procedure
Step
Operating instruction
Figure
1 Insert the flat-head screwdriver into the rectangular
opening of the spring-loaded terminal until it engages.
2
Remove the cable from the oval opening.
3 Remove the screwdriver.
