Siemens SIRIUS 3RM1 User Manual

Mounting
5.5 Mounting the devices on a fuse module
SIRIUS 3RM1 motor starter
Manual, 06/2016, A5E0345285095020A/RS-AE/005
91
5.5
Mounting the devices on a fuse module
Requirements
Make sure the rated operational current of the fuses fitted in the module is less than 25 A.
Procedure
Step
Description
Figure
1 and 2
• Push the 3RM1 motor starters into
the fuse module until the upper
and lower latches on the motor
starter enclosure snap into
position.
• Pull the device gently to check that
it is firmly seated.
See also
Connecting the fuse module (option) (Page 124)
