Siemens SIRIUS 3RM1 User Manual

Mounting
5.4 Mounting the devices on a standard mounting rail
SIRIUS 3RM1 motor starter
90 Manual, 06/2016, A5E0345285095020A/RS-AE/005
5.4
Mounting the devices on a standard mounting rail
Requirements
● At the installation location, a horizontal 35 mm mounting rail in accordance with
DIN EN 60715 is properly secured
● Please observe the information about the mounting position in chapter "Mounting position
(Page 63)"
Procedure
Step
Operating instruction
Figure
1 Hang the back of the device onto the upper edge of the
standard mounting rail
2 Press the lower half of the device against the rail until
the device engages
