Connection
6.7 Connecting the infeed system (option)
SIRIUS 3RM1 motor starter
122 Manual, 06/2016, A5E0345285095020A/RS-AE/005
Figure 6-3 Mount the 3RM19 infeed system
Hazardous voltage.
Will cause death or serious injury.
If free and uncovered terminal lugs are touched when the load voltage is switched on,
death or serious physical injury will result.
For this reason, always cover the free terminal lugs (= free slots that are unassigned for
thermal reasons, for example) with a cover cap. The cover caps are available as
accessories.
