Accessories
10.2 Accessories for constructing contactor assemblies for reversing and star-delta (wye-delta) start
SIRIUS - SIRIUS 3RA load feeders
126 Manual, 09/2016, A5E03656507520A/RS-AB/003
Accessories for the configuration of fuseless load feeders
The following optional accessories can be ordered as individual parts for the configuration of
fuseless load feeders:
● Accessories for starter combinations
● Accessories for DIN rail mounting
● Accessories for busbar mounting
Accessories for constructing contactor assemblies for reversing and
star-delta (wye-delta) start
The following accessories are available for starter combinations:
● Wiring kit for reversing operation
● Wiring kit for star-delta (wye-delta) starting
● Link module for the electrical and mechanical connection between motor starter protector
and contactor with screw-type, spring-loaded or hybrid connection system
Can be found in the appendix ...
About the wiring kit for reversing operation and
about the wiring kit for contactor assemblies for
star-delta (wye-delta) start
"References" under "Manuals - SIRIUS Modular
System (Page 140)" in the "SIRIUS - SIRIUS 3RT
Contactors/Contactor Assemblies" manual
The SIRIUS modular system features link modules to facilitate combinations involving the
following devices:
● Motor starter protector and contactor
● Motor starter protector and soft starter
● Motor starter protector and solid-state contactor (size S0 only)
The link module establishes the electrical and mechanical connection between motor starter
protector and contactor/soft starter/solid-state contactor. There are three different types
according to connection system:
● Link module for devices with screw-type connection system
● Link module for devices with spring-loaded connection system (sizes S00 and S0 only)
● Link module for hybrid connection (sizes S00 and S0 only)
