Configuration
6.2 Use of 3RA2 load feeders with highly energy-efficient motors (IE3)
SIRIUS - SIRIUS 3RA load feeders
Manual, 09/2016, A5E03656507520A/RS-AB/003
31
6.2.3
Technical modifications/restrictions of 3RV2 motor starter protectors
Restriction of the maximum starting current is necessary for one setting range each of sizes
S0, S2 and S3.
The reason for this lies in the corresponding variants' making and breaking capacities.
3RV2 motor starter protectors
3RV2.21-4E...
3RV2.3.-4R...
3RV2.4.-4M...
Setting range for overload release
27 to 32 A
70 to 80 A
80 ... 100 A
Reduced starting current ratio 8 times 9 times 7.8 times
Max. permissible starting current
32 A x 8 = 256 A
80 A x 9 = 720 A
100 A x 7.8 = 780 A
Starting current ratio:
Maximum permissible rated operational current [A]
3RV2.21-4E...
3RV2.3.-4R...
3RV2.4.-4M...
≤ 8 times
32.0
80.0
97.5 A
8.5 times 30.2 80.0 91.8 A
9 times
28.4
80.0
86.6 A
9.5 times
27.0
75.8
82.1 A
10 times
-
72.0
--
Note
For size S0, the setting range variants "
-4P" (30 to 36 A) and "-4F" (34 to 40 A) are not
suitable for use with IE3 m
otors.
We recommend the use of size S2 for these current ranges.
Extended setting ranges of overload releases (sizes S00 and S0)
For the following versions of the motor starter protectors (sizes S00 and S0), the setting
ranges of the overload releases have been extended and adapted to the lower rated motor
current of IE3 motors:
Size
Article number
Setting range for overload release
Previously
Setting range for overload release
New
S00
3RV2.11-4A…
11 to 16 A
10 to 16 A
S0
3RV2.21-4A…
11 to 16 A
10 to 16 A
3RV2.21-4B…
14 to 20 A
13 to 20 A
3RV2.21-4C…
17 to 22 A
16 to 22 A
3RV2.21-4D…
20 to 25 A
18 to 25 A
