Accessories
10.5 Accessories for busbar mounting
SIRIUS - SIRIUS 3RA load feeders
132 Manual, 09/2016, A5E03656507520A/RS-AB/003
Table 10- 7 Assembly kit for reversing operation for busbar (size S2)
Busbar adapters and device holders
Connector for contactors (2x)
Wiring modules (top and bottom)
Auxiliary wiring module (top and bottom) Screw and plain washer for mounting devices (2x)
The following accessories can also be ordered separately.
● Busbar adapter:
For 60 mm busbar center-to-center spacing. 2 lengths, 200 mm (only size S00 with
screw-type connection system) and 260 mm. With connecting cables.
● Device holder (sizes S00 and S0 only):
For 60 mm busbar center-to-center spacing. 2 lengths, 200 mm and 260 mm. Without
connecting cables.
● Busbar adapter and device holder (size S2):
For 60 mm busbar center-to-center spacing. 260 mm long. With connecting cables.
● Vibration and shock kit 8US1998-1DA10 (size S2) for busbar mounting under severe
ambient conditions.
Can be found in the chapter titled ...
About the available adapter types and
mounting the assembly kit for the busbar
On busbar system (Page 90).
