Mounting
7.1 Installation guidelines
SIRIUS - SIRIUS 3RA load feeders
36 Manual, 09/2016, A5E03656507520A/RS-AB/003
Table 7- 3 Installation guidelines for 400 V / 500 V / 690 V AC (size S3)
Clearance from grounded or live parts as well as from molded-plastic cable ducts according to IEC
60947-4
Motor starter protector
Contactor
Y1 [mm]
Y2 [mm]
X1 [mm]
X2 [mm]
Z [mm]
Rated operating voltage 400 V
3RV2.4
3RT204
On request
Rated operating voltage 500 V
3RV2.4
3RT204
On request
3RV2.4 + limiter (80 A)
3RT204
On request
Rated operating voltage 690 V
3RV2.42 + limiter (80 A)
3RT204
On request
7.1.2
Mounting variants under different conditions and frequency of use
The load feeders can be mounted horizontally or vertically.
Horizontal installation
Vertical installation
