Mounting
7.1 Installation guidelines
SIRIUS - SIRIUS 3RA load feeders
34 Manual, 09/2016, A5E03656507520A/RS-AB/003
Clearance from grounded or live parts as
well as from molded-plastic cable ducts according to
IEC 60947-4
Minimum clearance from contactor at the front. There is no minimum clearance requirement at the
front for the motor starter protector.
Note
Installation instructions for S0 motor starter protectors from 36 A
Minimum ca
ble length between motor starter protector and contactor: 150 mm.
Minimum clearance between motor starter protector and contactor: 100
mm.
