Mounting
7.1 Installation guidelines
SIRIUS - SIRIUS 3RA load feeders
Manual, 09/2016, A5E03656507520A/RS-AB/003
39
Combination
Setting range
Distance between feeders
Permissible installation: h = horizontal, v = vertical
Max. ambient temperature T
a
Use under increased vibration and shock
load
1)
Motor starter protector and contactor
A
mm h, v °C
Direct-on-line starter, spring-loaded connection, busbar
S00 ≤ 14 0 h 40 Vibration and shock kit 8US1998-1CA10
required
10 h 60
10 v 40
> 14 … 16 10 h 60
10 v 40
S0 ≤ 29 0 h 40 Vibration and shock kit 8US1998-1CA10
required
10 h 60
10 v 40
> 29 … 32 10 h 60
10 v 40
Reversing starter, spring-loaded connection, DIN rail or base plate
S00 ≤ 14 0 h, v 60 Unlimited
> 14 … 16 10 h 60
0 h, v 40
S0 ≤ 29 0 h, v 60 DIN rail adapter required
(already included with 3RA22)
> 29 … 32 10 h 60
0 h, v 40
Reversing starter, spring-loaded connection, busbar
S00 ≤ 14 0 h 60 Vibration and shock kit 8US1998-1CA10
required
0v 40
> 14 … 16 10 h 60
10 v 40
S0 ≤ 29 0 h 60 Vibration and shock kit 8US1998-1CA10
required
0v 40
> 29 … 32 10 h 60
10 v 40
