Procedure
1. Measure the output resistances R
o
of the load cells LC. Alternatively: Use the values from the
corresponding data sheet. Example:
Load cells Example values
LC 1: 1004.52 Ω
LC 2: 1003.64 Ω
LC 3: 1010.70 Ω
LC 4: 1028.12 Ω
2. Place the test weight on all four corners: Note the measured values
Load cells Example values
LC 1: 160 kg
LC 2: 148 kg
LC 3: 155 kg
LC 4: 152 kg
3. Determine the di󹪜erences from the smallest value:
Load cells Example values
Weights Di󹪜erence Result
LC 1: 160 kg LC 1 - LC 2 12 kg
LC 2: 148 kg -
1)
-
LC 3: 155 kg LC 3 - LC 2 7 kg
LC 4: 152 kg LC 4 - LC 2 4 kg
1)
Smallest value
Commissioning
6.3 Adjustment and initial commissioning
SIWAREX WL200
40 Operating Instructions, 12/2021, A5E02199611B-13
