Siemens Vector Control User Manual

Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-6 Operating Instructions SIMOVERT MASTERDRIVES
Para-
meters
depen-
dent on
P366
Designation of the
parameter on the
OP1S
Factory
setting with
PMU
Factory
setting with
OP1S
Cabinet unit
with
OP1S or
terminal strip
Cabinet unit
with PMU or
terminal strip
Cabinet unit
with NAMUR
terminal strip
(SCI)
(Src = Source) P366 = 0 P366 = 1 P366 = 2 P366 = 3 P366 = 4
BICO1
(i001)
BICO2
(i002)
BICO1
(i001)
BICO2
(i002)
BICO1
(i001)
BICO2
(i002)
BICO1
(i001)
BICO2
(i002)
BICO1
(i001)
BICO2
(i002)
P443 Src MainSetpoint KK058 KK040 KK040 KK040 KK040 KK040 KK058 KK040 KK058 K4102
P554 Src ON/OFF1 B0005 B0022 B2100 B0022 B2100 B0022 B0005 B0022 B2100 B4100
P555 Src1 OFF2 B0001 B0020 B0001 B0020 B0001 B0001 B0001 B0001 B0001 B0001
P556 Src2 OFF2 B0001 B0001 B0001 B0001 B0001 B0001 B0001 B0001 B0001 B4108
P565 Src1 Fault Reset B2107 B2107 B2107 B2107 B2107 B2107 B2107 B2107 B2107 B2107
P566 Src2 Fault Reset B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B4107 B4107
P567 Src3 Fault Reset B0000 B0018 B0000 B0018 B0000 B0010 B0000 B0010 B0000 B0000
P568 Src Jog Bit0 B0000 B0000 B2108 B0000 B2108 B0000 B0000 B0000 B0000 B0000
P571 Src FWD Speed B0001 B0001 B2111 B0001 B2111 B0001 B0001 B0001 B2111 B4129
P572 Src REV Speed B0001 B0001 B2112 B0001 B2112 B0001 B0001 B0001 B2112 B4109
P573 Src MOP UP B0008 B0000 B0000 B0000 B0000 B0000 B0008 B0000 B2113 B4105
P574 Src MOP Down B0009 B0000 B0000 B0000 B0000 B0000 B0009 B0000 B2114 B4106
P575 Src No ExtFault1 B0001 B0001 B0001 B0001 B0018 B0018 B0018 B0018 B0018 B0018
P588 Src No Ext Warn1 B0001 B0001 B0001 B0001 B0020 B0020 B0020 B0020 B0020 B0020
P590 Src BICO DSet B0014 B0014 B0014 B0014 B0012 B0012 B0012 B0012 B4102 B4102
P651 Src DigOut1 B0107 B0107 B0107 B0107 B0000 B0000 B0000 B0000 B0107 B0107
P652 Src DigOut2 B0104 B0104 B0104 B0104 B0000 B0000 B0000 B0000 B0104 B0104
P653 Src DigOut3 B0000 B0000 B0000 B0000 B0107 B0107 B0107 B0107 B0000 B0000
P693.1 SCI AnaOutActV 1 K0000 K0000 K0000 K0000 K0000 K0000 K0000 K0000 KK020 KK020
P693.2 SCI AnaOutActV 2 K0000 K0000 K0000 K0000 K0000 K0000 K0000 K0000 K0022 K0022
P693.3 SCI AnaOutActV 3 K0000 K0000 K0000 K0000 K0000 K0000 K0000 K0000 K0024 K0024
P698.1 Src SCI DigOut 1 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0100 B0100
P698.2 Src SCI DigOut 2 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0120 B0120
P698.3 Src SCI DigOut 3 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0108 B0108
P698.4 Src SCI DigOut 4 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0000 B0107 B0107
P704.3 SCom TlgOFF SCB 0 ms 0 ms 0 ms 0 ms 0 ms 0 ms 0 ms 0 ms 100 ms 100 ms
P796 Compare Value 100.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0 2.0 2.0
P797 Compare Hyst 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 1.0 1.0
P049.4 OP OperDisp r229 r229 P405 P405 P405 P405 r229 r229 r229 r229
Table 9-5 Factory setting dependent on P366
All other factory setting values are not dependent on P366 and can be
taken from the parameter list or from the block diagrams (in the
Compendium).
The factory settings for Index 1 (i001) of the respective parameter are
displayed in the parameter list.
Factory settings
dependent on P366
