Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-32 Operating Instructions SIMOVERT MASTERDRIVES
87654321
V/f characteristic (P100=2)
MASTERDRIVES VCTextile
- r2 -
P443.B
KK
Src main setpoint
P462.F (10 s)
Accel Time
P464.F (10 s)
Decel Time
n/f(set)
r482
n/f(set,smooth)
r229
P453.F (-110,0%) *
)
n/f(max,neg.spd)
n/f(max,pos.spd)
P452.F (110,0%) *
)
Volt.
Mod.
Depth
Asyc.
Mot. 3~
KK199
f(set,stator)
Smooth Vd(act)
P287.M
Setpoint channel Current limitation controller V/f characteristic Gating unit
Ref.
frequency: P352 *
)
speed: P353 *
)
Sheet 316 Sheet 317 Sheet 402 Sheet 405 Sheet 286
KK075
r014
Setpoint speed
Sheet 318
Current
lim.
r129
–
Boost end
frequency
P326.M
Mot.Freq.(n)
P107.M (50) *
)
Field weakening
frequency
P293.M
Mot.voltage
P101.M *
)
FSetp boost
P325.M *
)
Maximum
currents
P128.M
Imax controller Tn
P332.M
n/f(act)
r218
KK148
max.outp. volts
r346
Imax controller Kp
P331.M
P438.B (0)
KK
Src Add Setp2
P433.B (0)
KK
Src AddSetp.1
*
)
Parameter can only be adjusted in the "Drive setting" status (P60=5)
–
P330.M
Src Select Char.
Output Amps
N
2
3
6
4
n957.87 = 0
To Next Page
