Siemens Vector Control User Manual

Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-50 Operating Instructions SIMOVERT MASTERDRIVES
Board Meaning Parameter
value
CUVC Control Unit Vector Control 92
CUMC Control Unit Motion Control 93
CUMC+ Control Unit Motion Control Compact PLUS 94
CUVC+ Control Unit Vector Control Compact PLUS 95
CUPM Control Unit Motion Control Performance 2 96
CUMP
Control Unit Motion Control Compact PLUS
Performance 2
97
CUSA Control Unit Sinus AFE 108
TSY Tacho and synchronization board 110
SBP Sensor Board Puls 111
SCB1 Serial Communication Board 1 (fiber-optic cable) 121
SCB2 Serial Communication Board 2 122
T100 Technology board 131
T300 Technology board 131
T400 Technology board 134
CBX Communication Board 14x
CBP Communication Board PROFIBUS 143
CBD Communication Board DeviceNet 145
CBC Communication Board CAN Bus 146
CBL Communication Board CC-Link 147
CBP2 Communication Board PROFIBUS 2 148
EB1 Expansion Board 1 151
EB2 Expansion Board 2 152
SLB SIMOLINK bus interface 161
