05.2006 Parameterizing Steps
Siemens AG 6SE7087-2JD60
SIMOVERT MASTERDRIVES Operating Instructions 9-49
The visualization parameter r826.x is used for displaying the board
codes. These codes enable the type of installed electronic boards to be
determined.
Parameter Index Position
r826 1 Basic board
r826 2 Slot A
r826 3 Slot B
r826 4 Slot C
r826 5 Slot D
r826 6 Slot E
r826 7 Slot F
r826 8 Slot G
If a T100, T300 or TSY technology board (mounting position 2) or an
SCB1 or SCB2 (mounting position 2 or 3) is used, the board code can
be found in the following indices:
Parameter Index Position
r826 5 Mounting position 2
r826 7 Mounting position 3
Parameter value Meaning
90 to 109 Mainboards or Control Unit
110 to 119 Sensor Board (SBx)
120 to 129 Serial Communication Board (Scx)
130 to 139 Technology Board
140 to 149 Communication Board (Cbx)
150 to 169 Special boards (Ebx, SLB)
Board codes
General board
codes
