Table 1-1. Components of the Operator Interface (continued)
LED/Key
Description
Refer To
System Warning Keys and
LEDs
The System Warning LEDs – Supervisory and
Trouble – indicate when abnormal, non-fire
conditions occur to the fire alarm’s wiring or devices.
The System Warning keys – SUPV ACK and
TROUBLE ACK – allow an operator to acknowledge
the presence of the abnormal condition.
Chapter 3 for
Troubles.
Chapter 4 for
Supervisory
Conditions
System Reset Key
Pressing this key directs the panel to reset all
attached devices and clear all acknowledged
alarms, troubles, and supervisory conditions.
Chapter 2
AC Power LED
Indicates the presence of AC power at the panel.
N/A
Event Time Key
Used to display the time at which an acknowledged
alarm, trouble, or supervisory condition occurred.
Chapter 6
Entry Keypad
Used to call up points for monitoring and control.
Chapter 5
Facility-Specific Control
Keys
These are programmable keys. Typical functions
include manual evacuation, ground fault monitor,
etc.
N/A
Enable/Disable Keys
Pressing these keys allows you to enable or disable
devices attached to the panel.
Chapter 6
On/Off/Auto Keys
Pressing these keys allows you to force a device
(such as a relay) ON or OFF. The Auto key returns
control of the device to the panel.
Chapter 6
Arm/Disarm Keys
Used with security points. These keys allow you to
turn security devices on (arm) or off (disarm).
Chapter 6
Alphanumeric Display
Displays text describing abnormal conditions for
devices attached to the panel (i.e., smoke detector
in main lobby is in alarm). Also displays system
prompts and messages.
Important Note: The degree to which you are allowed to control the system depends on the passcode
assigned to you. See “Logging in and Out of the System” for details on this.
