7
Use the following procedure if the Global Acknowledge option is enabled on your system.
1. Unlock and open the enclosure door. Read the alphanumeric display on the interface panel.
It reports the number of alarm conditions as shown below.
2. Press the Fire Alarm Ack key. Read and follow the instructions on the alphanumeric
display. After you press the Fire Alarm Ack key, the system responds as follows:
The tone-alert silences and the alphanumeric display reports pertinent information about
the alarm, such as the following:
The Fire Alarm LED changes from flashing to steady ON, and all alarm conditions are
acknowledged.
Pressing the Fire Alarm Ack key again displays information on the next alarm.
Continue to do this to review all alarms in the system.
Use the following procedure if the Individual Acknowledge option is enabled on your system.
1. Unlock and open the enclosure door. Read the alphanumeric display on the interface panel.
It reports the number of alarm conditions as shown below.
2. Press the ALARM ACK key. A report similar to the one shown below appears. Read and
follow the instructions on the alphanumeric display.
Continued on next page
Acknowledging an Alarm, Continued
50BGlobally
Acknowledging
Alarms
51BIndividually
Acknowledging
Alarms
**FIRE** Press <ACK> to review.
Fire =1 PRI2 = 0 SUPV = 0 TRBL=0
FIRST FLOOR EAST WING ROOM 31
PULL STATION FIRE ALARM
**FIRE** Press <ACK> to review.
Fire =1 PRI2 = 0 SUPV = 0 TRBL=0
FIRST FLOOR EAST WING ROOM 31
Press ACK key to acknowledge ALARM
PULL STATION ALARM
