Simplex 4100ES User Manual

46
To view Install Mode:
1. Press the Menu button.
2. Use the Arrows to Scroll to the Diagnostic Function option.
3. Press Enter.
4. From that menu, use the arrows to scroll down to the “View/Change Install Mode List” option.
5. Press Enter.
6. From “View Change Install Mode List” use the arrows to scroll down and select “View the
Install Mode List”
7. Press Enter to Display the List of items in Install Mode
Viewing Install Mode
Viewing Install Mode

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
