Simplex 4100ES User Manual

54
6. Press the <ENTER> key on the Display/Action keypad. If the test is successful, the following
message displays.
_______________________________________________________________________________
A TrueNAC status report can be generated by the panel with the completion of the TrueNAC
Voltage Drop Test.
Sample reports are shown below.
Example of a successful single-channel test:
-----------------------------------------------------------------
Service Port Page 1
Report 6: TrueAlert Device Status Report 10:23:45am WED 07-FEB-07
-----------------------------------------------------------------
TPS 3
SLC 1
POINT ID CUSTOM LABEL TEST RESULT
--------- ---------------------------------------- --------------
3-1-1 Cafeteria East PASSED
3-1-2 Cafeteria West PASSED
3-1-3 Main Lobby PASSED
3-1-4 Library East PASSED
3-1-5 Library West PASSED
NOMINAL CURRENT (A): 1.34
WORST_CASE CURRENT (A): 1.97
WORST_CASE VOLTAGE ABOVE/BELOW THRESHOLD (V): 0.9
SLC HAS NOT PASSED UNLESS ALL DEVICES ARE MARKED AS PASSED
---------------------------------------------------------------
_______________________________________________________________________________
Continued on next page
TrueNAC Voltage Drop Test, Continued
116BTesting each
TrueAlert Power
Supply’s SLC
117BThe TrueNAC Report
118BTrueNAC Report
Samples
TPS CARD: X Channel: X
TrueNAC TEST COMPLETED

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
