Simplex 4100ES User Manual

69
The FACP audio system provides the following functionality.
 Automatic, Pre-recorded Messages, which automatically play in response to system
events. For example, when a fire alarm is detected on the system, a message known as the
Primary Evacuation message automatically plays.
 Manually Selected, Pre-Recorded Messages. Some systems are capable of playing a
prerecorded message when a specific button is pressed. For example, you may press a button
to play an attention tone and phrase before using the microphone to make a live audio
announcement.
 Live Audio. Microphones connected to the audio system allow operators to issue live
announcement messages.
Refer to the page number listed in this table for information on a specific topic.
Topic
See Page #
Single Channel Audio Operation
70
Single Channel Audio Plus Paging
73
Two Channel Audio Operation
75
Three to Eight Channel Audio System Operation
79
Chapter 9
7BAudio Operations
124BIntroduction
125BIn this Chapter

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
