Simplex 4100ES User Manual

63
__________________________________________________________________________
1. Select View Test Results from the TrueAlert ES Self-Test menu
2. From the View Test Results screen, the user can select the results they wish to view. See
table 8-3 for the list of options.
Table 8–3. View Results Options
Option
Description
View Last Test Results*
Select this option to display the test results from the last
test performed by the panel.
The “failed” appliances are listed first, followed by
appliances that “passed” the Self-Test, and conclude with
the “unsupported” appliances.
View All Test Results
Select this option to display the latest results for all the
appliances that have ever been Self-Tested by the panel.
The “failed” appliances are listed first, followed by
appliances that “passed” the Self-Test, and conclude with
the “unsupported” appliances.
*Option selected by default.
_______________________________________________________________________________
TrueAlert ES Appliance Self-Test , Continued
Viewing Test
Results

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
