2. Press the SUPV ACK key. Repeat this step and read the reports. The alphanumeric display
shows the area and type of condition. The tone-alert silences and the yellow LED glows
steady.
a. The tone-alert silences and the LED glows steady.
b. The display shows the area and type of problem, as shown below.
OR
3. Read the alphanumeric display. Investigate the problem to determine its cause. Restore or
replace the defective device (switch, wire, notification appliance) in accordance with the
manufacturer’s instructions, or call Simplex to repair the system.
When the problem causing the condition is corrected, the SUPERVISORY LED flashes and
the tone-alert sounds steady.
4. Press the SUPV ACK key. The display shows the system status.
5. Press the SUPV ACK key again. After a short delay, the display indicates that the system is
normal.
Acknowledging Supervisory Conditions, Continued
Individually
Acknowledging
Supervisory
Conditions
FIRST FLOOR EAST WING ROOM 31
Press <ACK> key to acknowledge
FIRST FLOOR EAST WING ROOM 31
FIRE PUMP MONITOR RUNNING

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
