Simrad AP50 Autopilot
100 20222410 / B
6.2 AP50 Control Unit
Dimensions:.................................................................................................See Figure 6-1
Weight: ...................................................................................................... 0.9 kg (2.0 lbs.)
Material:........................................................................................Epoxy coated aluminum
Supply:...................................................................... 12-32 VDC –10%/+30% via Robnet
Power consumption:.....................................................................................................3 W
Environmental Protection:......................................................IP56 (when panel-mounted)
Safe distance to compass:........................................................................... 0.35 m (1.0 ft.)
Color:......................................................................................................................... Black
Temperature:
Operating: ...............................................................–25 to +55°C (–13 to +130°F)
Storage:...................................................................–30 to +70°C (–22 to +158°F)
Display:
Type:........................................................................................Backlit LCD matrix
Resolution:....................................................................................160 x 128 pixels
Illumination: ..................................................................................Adjustable in 10 grades
Mounting: .......................................................... Panel mount or bracket mount (optional)
Cable:................................................Robnet cable 15 m (49 ft.) with one male connector
Figure 6-1 AP50 Control Unit Dimensions
