Simrad AP50 Installation Manual

Simrad AP50 Autopilot
106 20222410 / B
6.9 RF45X Rudder Feedback Unit
Dimensions:......................................................See Figure 6-6, Figure 6-8 and Figure 2-6
Weight: ...................................................................................................... 1,0 kg (2,2 lbs.)
Material: .................................................................................................Polyacetal (POM)
Supply voltage:................................................12-24 VDC –10%/+30%, system supplied
Environmental Protection:...........................................................................................IP56
Temperature range:
Operation: ...............................................................–25 to +55°C (–13 to +130°F)
Storage:..................................................................–30 to +70°C (–22 to + 158°F)
Cable:.................................................................................................................. 2 m (6 ft.)
Rudder angle:..............................................................................................................± 45°
Output signal: .........................................................Polarity-independent frequency signal
Frequency resolution: ...........................Center: 3400 Hz, 20 Hz/degree of change
Linearity:........................................................................... ± 3° up to 45° of rudder
Current output for rudder angle indicator (only for stand-alone system).. 0.1mA - 1.1mA
Number of indicators (only for stand-alone system):......................................... 5 in series
Figure 6-6 RF45X Rudder Feedback Unit Dimensions
6.10 RF14XU Rudder Feedback Unit
Dimensions: ................................................................................................See Figure 6-7
Weight: ...................................................................................................... 2,8 kg (4,9 lbs.)
Material:............................................................................Reinforced glass fibre polyester
Environmental Protection: ..........................................................................................IP56
Ambient temperature:
Operation: .......................................–15 - +55°C (+5 to +130°F)
Storage:.........................................–30 to +70°C (–22 to +158°F)
Supply voltage: .................................................................................24VDC –10%/+30%
