Simrad AP50 Installation Manual

Simrad AP50 Autopilot
102 20222410 / B
6.4 JD5X Distribution Units
Dimensions:.................................................................................................See Figure 6-3
Weight: ...................................................................................................... 3.5 kg (7.7 lbs.)
Material:..............................................................................................Anodized aluminum
Supply voltage:.................................................................................24 VDC –10%/+30%
Reverse voltage protection ........................................................................................... Yes
Environmental Protection (IEC60945 Rain and spray protected):..............................IP44
Power consumption:....................................................................5 Watt (electronics only)
Robnet Supply:...............................................................................2.5A (automatic fused)
Drive engage (Bypass/Clutch, Auto, Handshake):............................................ Max 1.5 A
Solenoids, externally supplied.........................................................JD5X: Maximum 3 A
Motor/solenoid drive:................................... JD5X: 10 A continuous, 20 A for 5 seconds
Vbat output:...................................................................................2.5 A (automatic fused)
Safe distance to compass:................................................................................ 1.5 m (5 ft.)
Temperature range:
Operation: .............................................................. –25 to +55°C (–13 to +130°F)
Storage:...................................................................–30 to +70°C (–22 to +158°F)
Heading Sensor input: ..................................................Composite pulse width modulated
Rudder feedback input:.....................................Frequency signal, 3400 Hz, 20 Hz/degree
Rudder feedback units:........................................................................RF45X or RF14XU
FU/NFU control input .................................................................................................. Yes
NMEA input/output ports:........................................................................................... Two
External Alarm: ..................................................Open collector 0.75 A (automatic fused)
Mounting: .................................................................................................Bulkhead-mount
System selector Autopilot/Main steering system input:....................Potential free contact
Heading output: Simrad and Furuno radar display (clock/data; 0-5 V, 10 mA, 50 msec.)
Steering gear interface:
JD50 Distribution Unit:
Solid state output: ......................Switching low DC (19-40 V) single channel. 3 A.
JD51 Distribution Unit:
Solid state output: ........................ Switching high DC (110 V) single channel. 1 A.
JD52 Distribution Unit:
Solid state output: ..........Switching high/low AC (110-220 V) single channel. 1 A.
JD53 Distribution Unit:
Analog voltage control, internal supply: ..............Control range ±10 V, max. 5 mA
Galvanic isolated
Analog voltage control, external supply: .......................................Uext 5-24 VDC,
max. contol range 1.5 V to Uext – 1.5 V, max. 5 mA
