Simrad AP50 Installation Manual

Software Set-up Procedure
20222410 / B 65
Set-up item
(abbrev. name)
Equipment
connected
(name)
Connected to terminal
(use one available from list)
Assign hardware
port to set-up item
(* = default setting)
FLUX1 Not connected – – – –
RC25 Connection to Robnet ROBNET*
Distribution unit: HS+, HS– J50-HS
JD5X, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
CI300X, Analog terminal CI300X
FLUX2 Not connected – – – – *
RC25 Connection to Robnet ROBNET
Distribution unit: HS+, HS– J50-HS
JD5X, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
CI300X, Analog terminal CI300X
WIND Not connected – – – – *
JD5X, Main PCB NMEA I/P RX1+,RX1– J50-1
JD5X, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
DEPTH Not connected – – – – *
JD5X, Main PCB NMEA I/P RX1+,RX1– J50-1
JD5X, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
LOG Not connected – – – – *
JD5X, Main PCB NMEA I/P RX1+,RX1– J50-1
JD5X, Power PCB NMEA I/P RX2+,RX2– J50-2
NI300X, NMEA port #1 NI300-1
NI300X, NMEA port #2 NI300-2
NI300X, NMEA port #3 NI300-3
NI300X, NMEA port #4 NI300-4
GI51 Pulse log terminal GI-LOG
JD5X = All distribution unit models
