Simrad GC80/GC85 Expanded Gyro Compass
94 20221529 / C
JUMPER DEFAULT FUNCTION DESCRIPTION
J9 3-4 short Alarm contact setting
Output port: GTERM board, TB1
"ALCN"
1-2 Short = Alarm "CLOSES",
Normal "OPEN"
3-4 Short = Alarm "OPEN",
Normal "CLOSES"
NOTE: Never use both jumpers
at the same time!
J10 3-4 short Running contact setting
Output port: GTERM board, TB1
"RNCN"
1-2 Short = Alarm "CLOSES",
Normal "OPEN"
3-4 Short = Alarm "OPEN",
Normal "CLOSES"
NOTE: Never use both jumpers
at the same time!
