Simrad GC80 EXPANDED User Manual

Simrad GC80/GC85 Expanded Gyro Compass
96 20221529 / C
JUMPER DEFAULT FUNCTION DESCRIPTION
J8 3-4 short
Output port: GTERM board, TB2:
"5TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
J9 3-4 short
Output port: GTERM board, TB2:
"6TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
J10 3-4 short
Output port: GTERM board, TB2:
"7TX"
1-2 short = IEC-61162-2 or
TOKIMEC version
3-4 short = IEC-61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
J11
3-4 short Output port: GTERM board, TB2:
"8TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
J12 3-4 short
Output port: GTERM board, TB1:
"9TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
Serial signal
output
settin
g
, cont.
