DIP SWITCH SETTINGS
20221529 / C 97
JUMPER DEFAULT FUNCTION DESCRIPTION
J13 3-4 short
Output port: GTERM board, TB1:
"10TX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC-61162-1 ed.2
Ref. page 4.
NOTE
: Never use both jumpers
at the same time!
J14
3-4 short
Output port: GTERM board, TB2:
"GTX"
1-2 short = IEC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
Ref. page 4.
NOTE
: The true heading
information on "Gyro-
compass" is output
regardless of a system
change.(with HDM or
EHS unit). However,
when a "standard
external heading
sensor" is connected,
the true direction of the
selected sensor is
outputted.
NOTE
: Never use both jumpers
at the same time!
J15 Open
J16 Open
Type setting
Short = Standard
Open = With an external
heading sensor (with
HDM or EHS unit)
J17 Short
Software install or
internal
Short = Internal
communication with
"External heading
sensor "
Open = Software is installed in
SCCpwb
NOTE
: Be sure to set "J6" of
"SCCpwb" to "OPEN".
NOTE
: A damage will be
given to a circuit if
software is installed
while this jumper has
been short.
Serial signal
output
settin
To Next Page
