Simrad GO XSE Series Installation Manual

Connectors
5" unit rear connections
1 2
1 Sonar - CHIRP, Broadband, DownScan, and SideScan
imaging (dependent on the transducer)
2 Power 12 V DC supply input and NMEA 2000
7", 9" and 12" units rear connections
1
2
3
4
RADAR NMEA2000 POWER SONAR
1 Radar - radar (Ethernet) connection
2 NMEA 2000 - data input / output
3 Power - 12 V DC supply input
4 Sonar - CHIRP, Broadband, DownScan, and SideScan
imaging (dependent on the transducer)
