Installation
General mounting guidelines
Warning: Do not install the unit in a hazardous/
flammable atmosphere.
Ú
Note: Choose a mounting location that will not expose the unit
to conditions that exceed the technical specifications.
Mounting location
This product generates heat which must be considered when
choosing the mounting location.
Ensure that the selected area allows for:
• Cable routing, cable connection and cable support.
• Connection and use of portable storage devices.
• Viewing any LED indicators.
• Easy access to serviceable parts.
Do also consider:
• The free space around the unit to avoid overheating.
• The mounting surface’s structure and strength, with regard to
the weight of the equipment.
• Any mounting surface vibration that might damage the
equipment.
• Hidden electrical wires that might be damaged when drilling
holes.
Ventilation
Inadequate ventilation and subsequent overheating of the unit may
cause reduced performance and reduced service life.
Ventilation behind units is recommended for all units which are not
bracket mounted.
Ensure that cables do not obstruct the airflow and that the
ventilation holes are not blocked.
Examples of enclosure ventilation options, in order of preference,
are:
2
14
Installation | GO XSE/XSR Installation Manual
