Network echosounder mode

The network echosounder mode setting selects whether only one

or multiple echosounder sources can be selected at the same time.

Note: Single source is automatically selected if there are older

legacy echosounders on the network. You cannot change this

setting if older legacy echosounders are on the network. Multi-

source mode should be selected if no legacy echosounder is

connected to the network.

Note: When changing the mode to multi-source you must wait

30 seconds and then power down all sources. Wait 1 minute,

then restart all connected sources.

Use network depth and temp data

The unit can share depth and temperature data from an Ethernet

networked echosounder source over the NMEA 2000 network.

Use this option to select from which Ethernet network source the

data is shared.

Autopilot settings

The Autopilot settings dialog depends on which autopilot

computer that is connected to the system. If more than one

autopilot is connected, the Autopilot settings dialog shows option

for the active autopilot.

The settings are made during commissioning of the autopilot. Be

careful of changing settings after commissioning is completed.

NAC-1 specific installation settings

Commissioning

Used to calibrate your boat’s steering (cable steer or hydraulic

steering) with the NAC-1.

System setup | GO XSE/XSR Installation Manual
