Simrad GO XSE Series Installation Manual

Dimensional drawings
5" unit
152.0 mm
(5.98”)
94.0 mm
(3.70”)
120 mm
(4.72”)
94.0 mm
(3.70”)
117.5 mm
(4.62”)
58.0 mm
(2.28”)
136.0 mm
(5.35”)
7" unit
197.0 mm
(7.76”)
220.0 mm
(8.66”)
126.9 mm
(5.00”)
74.7 mm
(2.94”)
8.0 mm
(0.32”)
141.0 mm
(5.56”)
154.9 mm
(6.10”)
202.2 mm
(7.96”)
61.9 mm
(2.44”)
62
Appendix | GO XSE/XSR Installation Manual
