Simrad GO XSE Series - Page 63

9" unit
242.0 mm
(9.52”)
263.0 mm
(10.35”)
24.0 mm
(0.94”)
184.0 mm
(7.24”)
170.0 mm
(6.69”)
8.0 mm
(0.31”)
90.0 mm
(3.54”)
79.0 mm
(3.11”)
12" unit
310.0 mm
(12.20“)
74.7 mm
(2.94“)
323.5 mm
(12.74“)
219.1 mm
(8.63“)
233.2 mm
(9.18“)
8.0 mm
(0.32“)
95.0 mm
(7.74“)
110.6 mm
(4
.36“)
Appendix | GO XSE/XSR Installation Manual
63
