Simrad GO XSE Series Installation Manual

Contents
9 Introduction
9
Parts included
11 Front controls
12 Card reader
13 Connectors
14 Installation
14 General mounting guidelines
17 Bracket mounting
21 Panel mounting
21 Bezel fitment and removal
22 Wiring
22 Connectors
22 Wiring guidelines
23 Power connections
24 Power control connection
26 External alarm
27 Connecting control devices
27 NMEA 2000
30 Echosounder
31 Radar connector
32 System setup
32 Turning the system on and off
32 First time startup
32 System setup sequence
32 The settings dialog
33 System settings
35 Feature option
35 Alarms
35 Radar installation
40 Echosounder settings
45 Autopilot settings
47 Fuel settings
50 Wireless settings
51 Network settings
Contents | GO XSE/XSR Installation Manual
7

Simrad GO XSE Series Specifications

General

Touchscreen	Yes
Chartplotter	Yes
Resolution	1280 x 720 pixels
Chart Compatibility	C-MAP, Navionics
Radar Compatibility	Compatible with Simrad HALO radar
Card Slots	MicroSD card slot
Operating Voltage	12V DC
Operating Temperature	-15°C to 55°C
Weight (7")	0.9 kg
Display Size	7", 9"
GPS	Built-in GPS
Sonar	CHIRP
