Installation
Box contents
EN
G
LIS
H
I
nstallat
ion
Ma
n
u
a
l
ENGLI
S
H
I
n
stallation M
anua
l
EN
G
LI
SH
I
nst
allatio
n M
a
nual
ENGLIS
H
I
nstallat
i
on M
a
nual
3
4
2
1
10
5
6
7
8
9
11
1
Control unit
2
Panel mounting gasket
3
Sun cover
4
Bezels
5
Gimbal inserts (R3016 only)
6
Power cable
7
Knobs
8
Fixing screws
9
Documentation pack
10
U-brackets
11
U-bracket straps (one for R2009, two for R3016)
Mounting location
Choose the mounting locations carefully before you drill or cut. The unit should be mounted
so that the operator can easily use the controls and clearly see the screen.
9
36
Installation
| R2009/R3016 User manual
34
36
